Products

Technical Parameters

• Colour Colour coded according
  Working Load Limit with 1 webbing sling
  Straight lift
  Choked lift
  ø
  Working Load Limit with 2 webbing sling
  Straight 45°
  Choked lift up to 45°
  Straight lift 45-60°
  Choked lift 45-60°
• - - - - 0-7° 7-45° 45-60° ‹ 45° ‹ 45° 45-60° 45-60°
• - -
• - - 1 0.8 2 1.4 1 1.4 1.12 1 0.8
• WLL 1T E7DEE010 1,000 800 2,000 1,400 1,000 2,800 1,120 1,000 800
• WLL 2T E7DEE020 2,000 1,600 4,000 2,800 2,000 5,600 2,200 2,000 1,600
• WLL 3T E7DEE030 3,000 2,400 6,000 4,200 3,000 8,400 3,360 3,000 2,400
• WLL 4T E7DEE040 4,000 3,200 8,000 5,600 4,000 11,200 4,480 4,000 3,200
• WLL 5T E7DEE050 5,000 4,000 10,000 7,000 5,000 14,000 5,600 5,000 4,000
• WLL 6T E7DEE060 6,000 4,800 12,000 8,400 6,000 16,800 6,720 6,000 4,800
• WLL 8T E7DEE080 8,000 6,400 16,000 11,200 8,000 22,400 8,960 8,000 6,400
• WLL 10T E7DEE100 10,000 8,000 20,000 14,000 10,000 28,000 11,200 10,000 8,000
• WLL 12T E7DEE120 12,000 9,600 24,000 16,800 12,000 33,600 13,440 12,000 9,600
